Vegetable Fruit Processing Machine

Grape Straw berry pneumatic wine press machine for wine castle cellar vineyard Bodega

  • Capcity: Whole grapes 1000kg Crushed grapes Fermented skin residue
  • Power: 5.5KW
  • Voltage: 220v/380v
  • Ports: Qingdao/Ningbo
  • Size: 2.89*1.65*1.8m
  • Payment: T/T,L/C,Western Union,MoneyGram, other

Send an E-mail to us!

(※ Click this button to inquiry)

  • Grape Straw berry pneumatic wine press
  • Grape Straw berry pneumatic wine press
  • Grape Straw berry pneumatic wine press
■ Application and Features

 2m³ airbag press configuration

1. Party B's product design bilingual operation mode (Chinese, English)

2. A waterproof cover is added to the operation panel, suitable for outdoor use

3. Voltage: three-phase 240v; (can be customized)

4. Axial feed DN100; (optional)

5. PLC control, preset 2 standard programs, touch screen can realize the setting of any pressing cycle program;(Multiple standard programs can be customized)

6. The main body and pipes of the equipment are all made of SUS304 stainless steel;

7. Equipped with casters, flexible movement, the length of the power cord is 20 meters;

8. The inside of the pressing chamber is equipped with three juice separation screen grooves, which communicate with the external juice collection port;

9. The juice collection port is equipped with a threaded connection plug, which can be easily connected to the pipeline, effectively increasing the pressing separation area and improving the separation effect;

10. The collection tank is 300L, and the DN50 interface is installed; (can be customized)

11. Infrared induction safety protection.

12. The area of the juice outlet hole of the pressing chamber can be customized, and the size of the feeding door can be customized.





■ Specifications

Model

Tank volume (L)

Whole grapes

Crushed grapes

Fermented skin residue

 Voltage

Maximum pressure MPA

MACHINE SIZE

HLQNYZ-20

20

10kg

20kg

20kg

220v 1.1kw

0.3

1*0.55*0.9m

HLQNYZ-50

50

30kg

50kg

50kg

380v 2kw

0.3

1.15*0.7*0.9m

HLQNYZ-100

100

60kg

100kg

100kg

380v 2kw

0.3

1.3*0.8*1m

HLQNYZ-300

300

200kg

300kg

300kg

380v 2kw

0.3

1.4*1.25*1.3m

HLQNYZ-500

500

300kg

500kg

500kg

380v 3.5kw

0.3

1.89*1.1*1.21m

HLQNYZ-1000

1000

700kg

1000kg

1000kg

380v 4.6kw

0.3

2.6*1.65*1.5m

HLQNYZ-1500

1500

1000kg

1500kg

1500kg

380v 5.5kw

0.3

2.89*1.65*1.8m

HLQNYZ-2000

2000

1400kg

2000kg

2000kg

380v 5.5kw

0.3

3.2*1.8*2.15m

HLQNYZ-3000

3000

2000kg

3000kg

3000kg

380v 5.5kw

0.3

3.55*1.98*1.8m

HLQNYZ-5000

5000

3000kg

5000kg

5000kg

380v 7kw

0.3

4*2.1*2.1m
